Supports and hangers are important components used to support, fix and adjust pipelines, equipment and other mechanical facilities. They are usually installed at different locations in the pipeline system to ensure that the pipeline maintains a stable structure and position during operation. Supports and hangers ensure the safety, stability and long-term operation of the pipeline system by bearing the weight, thermal expansion, vibration and other forces of the pipeline. It is widely used in industries such as petroleum, natural gas, chemicals, electricity, metallurgy, and construction, and is an indispensable and important component in the pipeline system. Supports and hangers are usually made of materials such as steel and aluminum alloy, and can be customized according to actual needs. Depending on the working conditions and installation environment of the pipeline, the design of supports and hangers can have different types, specifications and load-bearing capacities.

Phone

+86 15733710333

info@global-flange.com

WhatsApp / WeChat

+86 15733710333

Related Products

List

1. Product features:

Strong load-bearing capacity:
The support and hanger can effectively support the weight of pipelines, equipment and other mechanical facilities to ensure the stability and safety of the system.

Adjustment function:
Some support and hanger designs have adjustment functions, which can adjust the installation height and position according to the actual needs of the pipeline to adapt to changes such as expansion and contraction of the pipeline.

Corrosion resistance:
The support and hanger are usually made of anti-corrosion materials, have good corrosion resistance, and are suitable for use in harsh environments, such as oceans, chemical plants, etc.

Wide applicability:
The support and hanger can be designed according to the working pressure, working temperature, medium characteristics and other requirements of the pipeline, and is suitable for various types of pipeline systems, such as water pipes, steam pipes, gas pipes, etc.

Easy installation:
The support and hanger are reasonably designed, easy to install and maintain, and can quickly and accurately fix the pipeline, reducing the installation cost.

Seismic resistance:
The support and hanger can effectively absorb vibration, reduce the damage to the pipeline during vibration, and increase the stability of the pipeline system.

Flexibility:
The support and hanger have a variety of different design styles, which can adapt to different pipeline systems and installation environments, and have high flexibility.

2. Technical parameters:

Material	Carbon steel, stainless steel, aluminum alloy, plastic, etc.
Specification	Provide various specifications of supports and hangers according to the size, weight, type and use requirements of the pipeline
Operating temperature	-20°C ~ +600°C (depending on the type and material selection)
Work Pressure	According to different needs, the support and hanger can withstand pipeline loads of different pressures.
Carrying capacity	The load-bearing capacity of the supports and hangers can range from tens of kilograms to several tons, and can be customized according to the pipe weight and requirements.
Connection	Flange connection, bolt connection, welding connection, etc.

3. Common types:

Fixed supports (fixed brackets):
Used to fix a certain position of the pipeline to prevent the pipeline from moving in the axial, radial or angular direction. Suitable for pipelines that do not require large-scale expansion.

Sliding supports:
This type of support allows the pipeline to slide freely in a certain direction, and is suitable for situations where it is necessary to compensate for the thermal expansion or displacement of the pipeline.

Adjustable supports:
This type of support is designed with an adjustment function, which can be adjusted according to the actual height or position change of the pipeline to ensure that the pipeline is always in the best position.

Spring supports:
Applicable to occasions where it is necessary to absorb pipeline load changes and vibrations, which can effectively reduce the expansion force of the pipeline caused by temperature changes and ensure the stability of the pipeline.

Shock-absorbing supports:
Designed to slow down the stress changes caused by vibration or impact on the pipeline, usually including springs, rubber and other materials, which can effectively reduce the risk of pipeline damage.

Bracket supports:
A type of support for lifting pipelines, suitable for lower positions of pipelines or supporting pipelines with larger diameters.

Hanger: A hanger used to hang pipes. It is usually used to hang pipes through a hanger or chain. It is widely used for high-altitude or special pipe installation.

4. Application areas:

Oil and gas: In oil and gas pipeline systems, hangers are used to support and fix pipelines. Especially in places with large temperature fluctuations, hangers help compensate for pipeline expansion and displacement.

Chemical industry: In chemical plants, hangers are widely used in various chemical medium pipelines to help support and fix pipelines and prevent pipeline deformation or breakage.

Power industry: In steam pipes, cooling pipes and other systems in power plants, hangers not only support pipelines, but also absorb expansion and vibration caused by temperature changes to ensure safe and stable operation of power plant equipment.

Metallurgical industry: In metallurgical plants, hangers are used to support large pipeline systems and reduce thermal expansion caused by high temperature and high pressure.

Construction industry: In construction, hangers can be used to support water pipes, gas pipes, cable pipes, etc. to ensure the stability of the pipeline system.

Municipal Engineering:
In municipal water supply and drainage systems, supports and hangers are used to support and fix pipelines to ensure the stability of pipelines during construction and use.

5. Advantages:

Improve the stability of the pipeline system:
Supports and hangers can bear the weight of the pipeline and prevent the displacement of the pipeline, ensuring the stability of the pipeline in long-term operation.

Strong adaptability:
Supports and hangers can be customized according to the working temperature, pressure and medium characteristics of the pipeline system to meet different application requirements.

Reduce pipeline damage:
By effectively supporting the pipeline, the stress caused by expansion or vibration of the pipeline during use is reduced, and the service life of the pipeline and equipment is extended.

Easy to install and maintain:
The support and hanger are simple in design, easy to install and maintain, and can reduce the difficulty and cost of engineering construction.

Improve safety:
By effectively supporting the pipeline, system failures caused by uneven force or displacement of the pipeline are avoided, ensuring the safe operation of the entire pipeline system.

Quality assurance:

Our support and hanger products are designed and manufactured in strict accordance with international standards and industry requirements, and undergo strict quality inspections to ensure product reliability and durability. Each product will undergo necessary strength, load-bearing, corrosion resistance and other performance tests before leaving the factory to ensure its excellent performance in practical applications.

6. Packaging and transportation:

Packaging: According to the specifications and quantity of the supports and hangers, wooden boxes, pallets and other packaging forms are used to ensure safety during transportation.

Transportation: Provide a variety of transportation methods, including sea, air, land, etc., to ensure that the products are delivered on time.

7. Precautions:

Inspection before installation:
When installing the supports and hangers, it is necessary to check whether the connection between the pipeline and the supports and hangers is firm to ensure a stable installation.

Regular inspection:
During use, it is necessary to regularly check the load and connection of the supports and hangers to avoid instability of the pipeline due to aging or damage.

Choose the right supports and hangers:
According to the load, temperature and pressure of the pipeline, choose the right supports and hangers to ensure that they can withstand the required load and perform at their best.

8. Summary:
As an important part of the pipeline system, the supports and hangers play a key role in ensuring the safe and stable operation of the pipeline. By properly selecting and installing supports and hangers, pipeline stress can be effectively reduced, pipeline stability can be improved, and the service life of the pipeline system can be extended. Whether it is petroleum, chemical, electric power or municipal engineering, supports and hangers are widely used in all walks of life and are indispensable components in pipeline systems.
